H-Series Rectangle Flag Pole System
The H-Series is our premium Rectangle Flag Pole hardware, designed for professionals who require maximum display area and structural integrity. Often referred to as a block or edge flag system, our Rectangle Flag Pole utilizes a patented carbon composite structure that outperforms traditional aluminum alternatives in both weight and wind resistance.
Hardware Engineering: Why H-Series?
- High-Resilience Material: This rectangle flag pole is crafted from carbon composite, allowing the set to bend and sway without permanent deformation—critical for the flat-top tension required by block flags.
- Integrated Elbow Joint: Every H-Series rectangle pole features a pre-bonded 92°/97° angled connector. This "Guai Zi" design provides a rigid horizontal support that standard telescopic poles lack.
- Precision Spindle Fit: Engineered with a 14.8mm inner diameter port, this rectangle flag pole hardware ensures a zero-wobble fit on 14.65mm spindles, facilitating 360° smooth rotation.
Patented 4-in-1 Compatibility
Our rectangle flag pole is a core component of our Patented 4-in-1 System. By using the H-Series base poles, distributors can switch between different display shapes (Feather, Teardrop, Shark Fin) simply by swapping the top sections or adding the horizontal arm.
Inventory Advantage: The H-Series horizontal arm (standard 695mm) can be stocked separately, allowing for modular upgrades to existing pole kits.
Validated Performance: 160km/h Wind Tunnel Test
Reliability isn't just a claim—it's proven. Our H-Series Rectangle Flag Poles underwent rigorous stress testing in a professional wind tunnel in Italy. Even when subjected to extreme wind speeds of 160km/h (Grade 14 Typhoon conditions), the carbon composite structure remained completely undamaged.
Structural Damage
Permanent Deformation
Shape Recovery
Note: This extreme resilience ensures that your hardware investments are protected against unpredictable outdoor weather, significantly lowering replacement costs compared to standard aluminum poles.
H-Series Rectangle Pole Specifications
| Size | Display Dimension | Flag Size | Pole Section | Approx. Gross Weight |
|---|---|---|---|---|
| H 2.1m | 2.1m | 1.7 × 0.7m | 3 | 0.9kg |
| H 3.0m | 3.0m | 2.5 × 0.7m | 3 | 1.12kg |
| H 4.2m | 4.2m | 3.3 × 0.7m | 4 | 1.5kg |
